K8C
KICKPI-K8C Cortex-A76 x4 + Cortex-A55 x4 processor RK3588, Support efficient secondary development and independent customization
- Strong Core Power: Cortex-A76 X4+ Cortex-A55 X4.Mali-G610 MC4 GPU, enjoy smooth graphics processing, supported by 6 TOPS NPU, it offers powerful computing power;
- Multi-screen Intelligent Control-free Expansion: Supports HDMI output up to 8K@60Hz and MIPI-DSI display connectivity up to 4K@60Hz for ultra-high-definition displays and versatile screen integration.
- High-speed Interconnection: Dual Gigabit Ethernet ensures stable, low-latency wired connectivity, while dual-band Wi-Fi and Bluetooth provide smooth 2.4GHz/5GHz wireless transmission.
- Efficient secondary development and independent customization: Embedded operating system underlying drivers, providing technical information
- Widely applicable fields: IoT gateways, customized markets for industries such as NVR storage, industrial control tablets, industrial testing, and in-car central control.
KICKPI-K8C, powered by the Rockchip RK3588, this high-performance development board features an octa-core CPU, Mali-G610 GPU, and 6 TOPS NPU for edge AI and advanced computing. With dual Gigabit Ethernet, Wi-Fi, Bluetooth, 8K HDMI output, and support for Android 14, Debian 12, and Ubuntu 24.04, it is ideal for AIoT, industrial control, edge computing, and multimedia applications.
- CPU: ARM A76 X4 + ARM A55 X4
- GPU: Mail G610 MC4
- NPU: RKNN 6 Tops
- Memory: 4GB / 8GB / 16GB /32GB
- Storage: 16GB / 32GB / 64GB
- Systems Supported: Android 14.0 / Debian 12 / Ubuntu 24.04
Application:
- Commercial Display
- Medical Technology
- Internet of Things
- Industrial Control
- AI Intelligence
- Industrial Inspection
Hardware interface:
Hardware Spec:
| Type | Main Specifications |
| Soc | Rockchip RK3588 |
| CPU | ARM A76 X4 + ARM A55 X4 |
| GPU | Mail G610 MC4 |
| NPU | RKNN 6 Tops |
| Memory | 4GB / 8GB / 16GB / 32GB |
| Storage | 16GB / 32GB / 64GB |
| Systems Supported | *Android 14 *Debian12 *Ubuntu 24.04 |
| Power Supply | DC 12V |
| Fan | MX1.25 2Pin |
| LED Light | *Power LED *Running LED |
| USB HOST | USB3.0 TYPE-A X1 USB2.0 TYPE-A X1 |
| USB OTG | USB2.0 TYPE -C |
| Real-Time Clock | MX1.25 2Pin |
| Debug Serial Port | PH2.54 3Pin |
| KEY | *RESET KEY *POWER KEY *RECOVERY KEY *MASKROM KEY |
| Extended Pins | *GPIO X19 *UART X4 *SPI X2 *PWM X5 *ADC X1 *I2C X2 *CAN X1 |
| HDMI OUT | X2 / 7680×4320@60Hz |
| MIPI DSI LCD | X1 / 4096×2160@60Hz |
| MIPI CSI CAMERA | FPC 22Pin 4LANE X1 |
| EarPhone | Audio Input/Output |
| WIFI / BT | VS6621U |
| Ethernet | 1000M x2 |
| TF Card | Y |
